Engine: two-stroke with flat piston, alloy cylinder and head.
Bore 68 mm Stroke 72, 246cc.
Power 8.5 HP @ 4,500rpm
Compression ratio: 6.03:1.
Lubrication: petroil 20:1
Exhaust: two exhaust pipes.
Fuel tank: capacity 11.3 litres.
Carburettor: Bing AJ 2/24
Spark plug: DM 175 A 1.
Lighting system: Noris MLZS 6/30 / 3a. - Headlight Noris SBT 160/3, light outlet 160 mm.
Clutch: two discs with cork blades.
Gearbox: Triumph-Hurth 4-speed, unit construction)
Drive: engine to gearbox via chain in oil bath. Rear wheel chain fully enclosed.
Brake drum: diameter 150 mm. Width 22 mm.
Tyres: 3.00x19.
Front Suspension: pressed-metal forks.
