Specification
Engine: Ardie two-stroke three-port type
Lubrication: 15:1 mixture by semi-automatic pressure pump with drip glass, B & B carburettor with replaceable nozzle, separate air and gas slides, spark plug from Bosch or Noris
Power: 3.5 nominal horsepower, 1.99 tax horsepower. 75 km/h
Displacement: 349 cc
Bore and stroke: 75 mm, 79 mm
Consumption: 3 litres of petrol per 100 km
Transmission: Sturmey-Archer three-speed transmission with cork blades hand clutch and kick starter, power transmission to the engine
Gear with 1/2” x 5/16”, gear to rear wheel chain 5/8”x1/4”
Fuel Tank: 10 litre tank with built-in oil container (another 1.5 litres) 1 litre reserve tank on the luggage rack for carrying Reserve gasoline or oil
Rims and tyres: 26x1/2” rim for 26x1/2” or 26x3” Continental Excelsior or Dunlop tyres
Brakes: 2 inner shoe brakes with Jurid pads, front wheel brake with hand lever, rear wheel brake with foot pedal
Electrics: Bosch or Noris Magneto
Weight: approx. 100 kg
Dimensions: saddle height 72 cm
Equipment: Ardie front fork, all springs completely greased filled steel cans, special reinforcement for sidecar use, tubular steel frame with special guaranteed break-proof reinforcements, can be dismantled into individual parts,
Lohmann saddle with double suspension, luggage rack suitable for pillion seat, 2 tool bags and reserve tank, handlebars touring style, also available with solid racing handlebars upon request
Aluminum running boards, particularly wide mudguards, exhaust pipe with exhaust flap, complete tool set in leather bag
Color: Black with gold piping
Accessories and extras: Racing handlebars on request
On request, the lighting was provided with Bosch or Noris
Price: 1,050 marks.
1,280,-- Mk. with Bosch ignition light
Source: ardie.de
