Manufactured by Moto Vespa SA
Based at Calle Julián Camarillo, 6 in Madrid, the company was formed in 1952 by Piaggio and Instituto Nacional de Industria (INI), the largest automotive producer in Spain.
Over the course of 50 years they built a considerable variety of motorcycles and scooters using in addition to the MotoVespa brand, those of Gilera, Vespa, Vespino and Piaggio.
The Vespino was introduced in 1968 and became the most popular moped in Spain, retaining that place for over 30 years until production ceased at the end of the millenium. It was exported to South America, Africa and several European countries.
In 1978 the P-range Vespa was introduced; the P200DS was built from 1978 to 81, followed by the P200DN. The Moto Vespa T5 appeared in 1986, soon joined by the similar TX200 - both of these had electric start.
At the end of the 1990s, Moto Vespa exported to 35 countries and had almost 1,000 employees.
Production ceased in 2003.
Vespa Models by MotoVespa include:
Gilera models by MotoVespa include:
MotoVespa 1974 160
CARACTERISTICAS TECNICAS
Motor
Número' de cilindros:
Ciclo:2 tiempos.
Diámetro:60 mm.
Carrera:57 mm.
Cilindrada:161,16 c. c.
Potencia:7,8 C. V. (a 5.200 r. p. m.)
Equipo eléctrico
Encendido electrónico
Avance encendido: 22° +/- 1°.
Bujia con capuchón antiparasitario.
Marcas de bujías:
... Firestone F. 27.
... Boch W 225 TI.
... Champion L. 86.
Datos diversos
Velocidad máxima:95 Km./h.
Pendiente máxima:35 %.
Consumo (CUNA) a los 100 Km.: 2,5 litros.
Capacidad total depósito: 7,7 litros.
Reserva: 1,4 litros.
Autonomía aproximada: 300 Km.
Dimensiones y peso
Altura máxima: 1.040 mm.
Longitud máxima: 1.780 mm.
Anchura máxima: 680 mm.
Distancia entre ejes: 1.240 mm.
Radio mínimo: 1.500 mm.
Peso total en vacío: 98 Kg.
1974 Vespa 160
TECHNICAL SPECIFICATIONS
Engine
Number of cylinders:
Cycle: 2-stroke.
Bore: 60 mm. Stroke: 57 mm. Displacement: 161.16 cc.
Power: 7.8 hp (at 5,200 rpm)
Electrical Equipment
Electronic ignition
Ignition advance: 22° +/- 1°.
Spark plug with anti-interference cap.
Spark plug types:
... Firestone F. 27.
... Bosch W 225 TI.
... Champion L. 86.
Miscellaneous Data
Maximum speed: 95 km/h
Maximum incline: 35%
Fuel consumption (CUNA) per 100 km: 2.5 litres
Total fuel tank capacity: 7.7 litres
Reserve fuel: 1.4 litres
Approximate range: 300 km
Dimensions and Weight
Maximum height: 1,040 mm
Maximum length: 1,780 mm
Maximum width: 680 mm
Wheelbase: 1,240 mm
Minimum turning radius: 1,500 mm
Empty Weight: 98 Kg.
Source: MotoVespa Factory Manual
Vespino NX Specification (1980 model)
Vespino NX 1980
Motor: Dos tiempos. Número de cilindros: Uno. Diámetro por carrera: 38,4 x 43 mm. Cilindrada total exacta: 49,77 mm. Relación de compresión: 8:1. Potencia máxima: 2,2 CV a 4.700 r.p.m.
Carburador: Un Dell'Orto, 12 mm, de diámetro.
Equipo eléctrico: Volante magnético. Embrague: Automático centrifugo. Cambio: Variador continuo de velocidad. Bastidor: Tubo de acero. Suspensión delantera: Horquilla telescópica. Suspensión trasera: Amortiguador muelles. Freno delantero: Expansión interna, 90 mm. de diámetro. Freno trasero: Expansión interna, 150 mm. de diámetro.
Neumáticos: Del.: 2,1/4 x 18. Tras.: 2,1/4 x 18. Longitud total: 1.760 mm.
Distancia entre ejes: 1.130 mm. Anchura máxima: 620 mm. Altura máxima: 1.030 mm. Peso: 52,400 kg. Capacidad del depósito: 3,3 litros. Velocidad máxima: 40 km/h. Consumo: 1,6 litros.
Engine: Two-stroke. Single cylinder. Bore x stroke: 38.4 x 43 mm. Total displacement: 49.77 cc. Compression ratio: 8:1. Maximum power: 2.2 hp at 4,700 rpm.
Carburettor: Dell'Orto, 12 mm diameter. Electrical system: Magneto flywheel. Clutch: Automatic centrifugal. Transmission: Continuously variable transmission (CVT).
Frame: Steel tube. Front suspension: Telescopic fork. Rear suspension: Shock absorber with coil springs. Front brake: Internal expanding disc, 90 mm diameter. Rear brake: Internal expanding disc, 150 mm diameter.
Tyres: Front: 2.25 x 18. Rear: 2.25 x 18.
Overall length: 1,760 mm. Wheelbase: 1,130 mm. Maximum width: 620 mm. Maximum height: 1,030 mm. Weight: 52.4 kg. Fuel tank capacity: 3.3 litres. Top speed: 40 km/h. Fuel consumption: 1.6 litres.
The Vespino NXA 1980 had Femsatronic electronic ignition.
Source: Motociclismo via Motoguapa
Sources: wikipedia.es; Scootering magazine.
