German Motorcycles

Horex Regina Specifications


HOREX Regina 0/1 342cc

Manufactured 1949-1958

TECHNICAL DETAILS & DATA

Model - Regina 0/1
Type - O.H.V. Single Cylinder
Cubic Capacity - 342cc.
Petrol Tank Capacity/R0 - 13.5 Ltr.
Petrol Tank Capacity/R1 - 18Ltr.
Petrol Tank Reserve/R0 - 2.5 Ltr.
Petrol Tank Reserve/R1 - 3Ltr.
Oil Tank Capacity - 2 Ltr.
Oil in Chaincase - 1.1/4 Ltr.
Bore - 69mm
Stroke - 91.5mm
Power - 18hp.
RPM - 5000rpm.
Gear Ratios

Bottom - 3.25
Second - 1.81
Third - 1.33
Top - 1

Carburettor

Bing, Nr: - AJ 2/26/11
(For Regina1 Sport Alloy head) Amal, Nr: 25 C2A
Ignition

Contact Breaker Point Gap - 0.3-0.5mm
Front Fork

Fork Oil - SAE 20.
Fork Oil Qty - 50ml. (25ml. ich)
Wheels

Front & Rear R0/1 - 2.5x19
Tyres Front & Rear R0/1 - 3.25x19


HOREX Regina 2 - 249cc (Horex 250)

Manufactured 1954-1956

TECHNICAL DETAILS & DATA

Model - Regina 2
Type - O.H.V. Single Cylinder , Alloy head
Cubic Capacity - 249cc.
Petrol Tank Capacity - 18Ltr.
Petrol Tank Reserve - 3Ltr.
Oil Tank Capacity - 2 Ltr.
Oil in Chaincase - 1.1/4 Ltr.
Bore - 65mm
Stroke - 75mm
Power - 14hp.
RPM - 6000rpm.
Gear Ratios

Bottom - 3.25
Second - 1.81
Third - 1.33
Top - 1

Carburettor

Bing, Nr: - 2/26/38
Bing, Nr: - 2/26/21
Ignition

Contact Breaker Point Gap - 0.4mm
Front Fork

Fork Oil - SAE 20.
Fork Oil Qty - 50ml. (25ml. ich)
Wheels

Front & Rear - 1.85x19
Tyres Front & Rear - 3.25x19



HOREX Regina 3 - 342cc

Manufactured 1952-1958

TECHNICAL DETAILS & DATA

Model - Regina 3
Type - O.H.V. Single Cylinder, Alloy head
Cubic Capacity - 342cc.
Petrol Tank Capacity - 18Ltr.
Petrol Tank Reserve - 3Ltr.
Oil Tank Capacity - 2 Ltr.
Oil in Chaincase - 1.1/4 Ltr.
Bore - 69mm
Stroke - 91.5mm
Power - 19hp.
RPM - 6250rpm.
Gear Ratios

Bottom - 3.25
Second - 1.81
Third - 1.33
Top - 1

Carburettor

Bing, Nr: - 2/26/43
Bing, Nr: - 2/26/23
Ignition

Contact Breaker Point Gap - 0.4mm
Front Fork

Fork Oil - SAE 20.
Fork Oil Qty - 50ml. (25ml. ich)
Wheels

Front & Rear - 1.85/2.15 Bx19
Tyres Front & Rear - 3.25/3.50x19


HOREX Regina 4 - 399cc (Horex 400)

Manufactured 1954-1956

TECHNICAL DETAILS & DATA

Model - Regina 4
Type - O.H.V. Single Cylinder, Alloy head
Cubic Capacity - 399cc.
Petrol Tank Capacity - 18Ltr.
Petrol Tank Reserve - 3Ltr.
Oil Tank Capacity - 2 Ltr.
Oil in Chaincase - 1.1/4 Ltr.
Bore - 74.5mm
Stroke - 91.5mm
Power - 22hp.
RPM - 5750rpm.
Gear Ratios

Bottom - 3.25
Second - 1.81
Third - 1.33
Top - 1

Carburettor

Bing, Nr: - 2/27.5/2.3
Ignition

Contact Breaker Point Gap - 0.4mm
Front Fork

Fork Oil - SAE 20.
Fork Oil Qty - 50ml. (25ml. each)

Wheels: Front 1.85 × 19, Rear 2.15 × 19
Tyres: Front 3.25 × 19, Rear 3.50 × 19

Source: Makis MC Classic


If you have a query about Horex motorcycles please contact us
