22/6 Tax
Full electric equipment. 8in. dia. head lamp.
4-speed Gear with POSITIVE STOP foot change.
Totally enclosed primary chain case.
ENGINE. " Levis " single-cylinder O.H.V., 67 m.m. bore, 70 m.m. stroke, 247 c.c. Detachable non-detonating turbulent head, single-port or two-port. Enclosed rocker gear. Rocker bearings and valve stems lubricated from crankcase.
COMPRESSION RATIO. 7.2 to 1.
GEAR RATIOS. 6.4, 8.2, 10.5 and 17.5 to 1.
TRANSMISSION. ½in. x .205 Primary Chain running in enamelled sheet steel chain cover. ½in. x .305 rear chain.
TYRES. 26 x 3.00 Dunlop. For alternative tyres see EQUIPMENT. Ribbed or Studded optional on front wheel.
BRAKES. 6in. diameter front and rear.
TANK CAPACITY. Petrol 2 gallons, Oil 3 pints.
PETROL AND OIL CONSUMPTION. Petrol 120 m.p.g. Oil 2,000 m.p.g. min.
SPEED. 63 m.p.h.
GROUND CLEARANCE, 5in.
WHEEL BASE. 52¾in.
SADDLE HEIGHT. 26in.
WEIGHT. 252 lbs.
FINISH. Chromium-plating throughout. For colour schemes see EQUIPMENT.
