| Engine | |||
| Configuration | Single camshaft Desmodromic,
2 valves per cylinder, 90° Vtwin, liquid cooled. |
Lubrication | |
| Bore & Stroke | 94 x 68 mm | Ignition | |
| Capacity | 944 cm3 | Charging system | 12 V - 420 W |
| Compression Ratio | 10.2 ± 0.5:1 | Starter | |
| Maximum Power | 61 kW (83 CV/HP) @ 8500 r.p.m. | Clutch | |
| Maximum Torque | Transmission | ||
| Fuel | Alfa/n Weber electronic indirect type - CPU 1.6M, 1 injector per cylinder | Gearbox | 1st 37/15
2nd 30/17 3rd 27/20 4th 24/22 5th 23/24 6th 24/28 |
| Inlet
Exhaust Valves |
Open 26° B.T.D.C.
Close 72° A.B.D.C. Open 61° B.B.D.C. Close 34° A.T.D.C Intake 43 mm, 11.8mm lift Exhaust 33 mm, 11.4mm lift |
||
| Chassis | |||
| Frame | Wheels | MT 3,50x17"
MT 5,50x17" Three-spoke light alloy |
|
| Dimensions
Weight:
Wheelbase:
Length:
Seat Height:
Ground Clearance:
|
207 kg 1430mm 2070mm 820mm 165 mm |
Tyres | 120/70 ZR 17"
170/60 ZR 17" |
| Front Suspension | Upsidedown, fully adjustable Ø 43 mm fork, 130mm travel | Brakes | Front Ø320 mm
Rear Ø245 mm |
| Rear suspension | Fuel Capacity | 21 Litres, 4L reserve | |
| Maximum speed 225 Km/h | |||
| Colour Scheme | Black, Red or Silver | ||
