Engine type
V60 Magnesium: four-stroke longitudinal 60° V-twin; liquid cooling with three-way pressurised circuit; double overhead camshaft operated by a mixed gear/chain system; four valves per cylinder; patent AVDC (Anti Vibration Double Countershaft
Fuel
Unleaded petrol
Bore and stroke
97 x 67.5 mm
Displacement
997.62 cc
Compression ratio
11.8 : 1
Maximum power at crank: 138.72 hp (102 kW) at 9,500 rpm Maximum torque : 10.9 kgm (107 Nm) at 7,500 rpm
Fuel system
Integrated electronic engine management system. Indirect multipoint electronic injection. Throttle body diameter: 57 mm. 10,3 litre airbox, with Air Runner air scoop.
Ignition
Digital electronic ignition, with one spark plug per cylinder and integrated injection
Starter
Electric
Exhaust
Double silencer with three-way catalytic converter and lambda sensor (Euro 2)
Alternator
12V - 500 W
Lubrication
Dry sump with separate oil tank. Double trochoidal pump with oil cooling radiator. Steel oil tank
Gearbox
Six speed. Ratios: 1st 34/15 (2.27), 2nd 31/19 (1.63), 3rd 26/20 (1.3), 4th 24/22 (1.091), 5th 24/25 (0.96), 6th 23/26 (0.88)
Clutch
Multiple disc wet clutch with patented PPC power-assisted hydraulic control. Braided metal clutch line radial pump with 15 mm piston.
Primary drive
Straight cut gears with ratio: 60/31 (1.935)
Final drive
Sprockets: 16 front, 40 rear
Frame
Box section sloping twin-spar aluminium alloy frame. Two-chamber adjustable Ohlins Racing steering damper with one-piece mounting.
Front suspension
Öhlins titanium nitride coated 43 mm diameter upside-down fork; 120 mm wheel travel. External hydraulic adjustment system for rebound, compression and preload. Lowered legs for radial caliper mounting.
Rear suspension
Double banana aluminium alloy swing arm and APS progressive system linkage.
Ohlins Racing hydraulic shock absorber with piggyback cylinder and adjustable rebound, compression and preload. 133 mm wheel travel.
Brakes
Front: Brembo dual 320 mm floating stainless steel disc. Radial caliper with four 34mm diameter pistons and 4 sintered pads. Braided metal brake line.
Rear: Brembo 220mm diameter stainless steel disc. Two-piston (32 mm diameter) caliper and sintered pads. Braided metal brake line.
Wheels
Forged aluminium alloy. Front: 3.50 x 17" Rear: 6.00 x 17"
Tyres
Tubeless radials. Front: 120/70 ZR 17, rear: 180/55 ZR 17 (alternative: 190/50 ZR 17)
Dimensions
Overall length: 2025 mm, Overall width: 730 mm (at handlebars), Overall height: 1135 mm (at windscreen), Saddle height: 820 mm, Handlebar height 830 mm (at bar ends), Wheelbase 1410 mm, Trail 101.7 mm, Steering angle 24.80°
Dry weight
185 Kg
Fuel capacity
18 litres (including 4 litres reserve)
Source: John Sample Group
