Configuration:
Single cylinder 4-stroke
Cooling:
Air cooled
Timing: Overhead camshaft with 4 valves
Capacity:
124.02cm3
Compression:
Ratio 10.8 : 1
Carburettor:
Mikuni BS 24
Ignition:
Electronic
Starter:
Electric - a ctivated by 12V battery & kick starter
Gear:
Change automatic converter
Primary Trans:
V Belt
End Transmission:
Transmission adapter with gears
Clutch:
Automatic centrifugal
Frame:
High tensile tubular steel split single-cradle
Wheels:
Light Alloys
Front:
3.00 x 12"
Rear:
3.50 x 10"
Tyres:
Front: 120/70 12"
Rear: 130/70 10"
Front Suspension:
Link rod fork with hydraulic shock absorbers, wheel travel 80mm
Rear Suspension:
Double-action single hydraulic shock absorber, wheel travel 75mm
Brakes:
Ø 190 mm front lightened stainless steel disc & 120mm rear drum brake.
Fuel Capacity:
7.7 litres (reserve 2.0 litres)
Dimensions:
Length: 1900 mm
Height:
1110 mm
Width:
720 mm
Dry Weight:
115 kg
Source: John Sample Group
