ENGINE. --2½ h.p., 70 x 76, M.O.I.V.
CARBURETTER. - Latest type semi-automatic multiple jet.
IGNITION. --Special light Bosch magneto.
FRAME. --New type open frame, with girder spring forks, giving low riding position.
TYRES. --Standard 26 x 2 in. Hutchinson non-skid. Other tyres according to cost.
MUDGUARDS. --3½ in. wide, fixed in a very rigid manner.
SILENCER. --" MATCHLESS," specially designed to suit this engine, with cut-out.
BELT. --7/8in. Shamrock Gloria.
PULLEY. --" MATCHLESS," adjustable.
BRAKES. --Front rim brake, hand-applied, and powerful driving rim brake operated by pedal.
SADDLE. --Middlemore's Rideasy, or to order.
CONTROL. --Carburetter, by thumb levers on handle-bar. Ignition, by ratchet lever on side of tank, and valve lifter.
TANK. --The tank fits in a specially designed frame, and contains one gallon of petrol and one quart of oil. The oil tank is fitted with semi-automatic forced sight feed lubricator.
FINISH. --Enamelled grey, and fine-lined gold and green.
GEAR. --Three speeds and free engine.
WEIGHT. --About 120 lbs.
PRICE. --51 Guineas. This price includes toolbag, full kit of tools, carrier, and number plates.
Stands are fitted to both wheels.
