Triumph 1961 650 Twin Engine Diagram

The 650 c.c. type illustrated here is the engine used, with minor variations, in all Triumph models of this capacity. Note the twin high-level camshafts driven by gears, the tremendously rigid crankshaft and the light alloy head with large diameter inclined valves...
