Moto Guzzi Stornello 125/160 1969

Specifications (125)

Engine :
Single-cylinder four-stroke. Bore x stroke: 52 x 58 mm, capacity: 123 cc. Compression ratio: 1: 9.6, maximum power: 13.5 DIN-PK at 7400 rpm. Carburetor: 22 mm. Lubrication: pressure lubrication with gear pump. Electrical installation: flywheel magneto 6 V, 28 W.

Transmission : Primary sprocket and secondary partially shielded chain. Multi-plate clutch in oil bath. Gearbox 5 speed. Kickstarter

Frame : double tubular frame

Suspension: Hydraulically damped front fork, rear swinging arm with two telescopic shock absorbers

Wheels and brakes: front wheel 2.50 x 17 and rear wheel: 3.00 x 17. Brakes front and rear: drum brakes

Fuel tank: 13.5 liters

Empty weight: 113 kg

Performance: maximum speed: 118 km/hour. Consumption: 3.7 liters per 100 km.

Specifications (160)

Moto Guzzi Stornello 160 5-Speed

Engine : Single-cylinder four-stroke. Bore x stroke: 58 x 58 mm, cylinder capacity: 153 cc. Compression ratio: 1: 9.6, maximum power: 16.2 DIN-PK at 7400 rpm. Carburetor: 22 mm. Lubrication: pressure lubrication with gear pump. Electrical installation: flywheel magnet 6 V, 28 W.

Transmission : Primary sprocket and secondary partially shielded chain. Multiple plate clutch in oil bath. Gearbox with 5 transmission ratio. Kickstarter

Frame : double tubular frame

Suspension: Hydraulically damped front fork, rear swinging arm with telescopic shock absorbers

Wheels and brakes: front wheel 2.50 x 17, rear wheel: 3.00 x 17. Drum brakes front and rear

Fuel tank: 13.5 liters

Empty weight: 113 kg

Performance: maximum speed: 125 km/hour. Consumption: 3.8 litres per 100 km.

Source: Moto Guzzi Database NL
