TECHNICAL SPECIFICATIONS
Engine 4-stroke, twin cylinder at V 90° Bore 80 mm, Stroke 74 mm
Displacement 743,9 cc
Compression ratio 9,7 to 1
O.H.V., 2-valve per cylinder
Lubrication by pressure pump Transmission primary by helical gears; secondary by cardan shaft and gears
Clutch dry with single disc
Fuel delivery two carburettors PHBH 30 with air filtering and engine gas recycling
Electrical system 12V. Alternator 14V-20A fitted on driving shaft, rectifier and regulator.
Battery 12V 24Ah
Starting electric
Ignition electronic
Gearbox 5-speed
Brakes two front discs 270m, independently controlled; one rear disc 235 mm
Integral Braking System device
Wheels light alloy
Tyres front 100/90 V18 rear 120/80 V18
Suspension front Moto Guzzi telescopic fork with pressure equalizer; rear light alloy swinging fork with oil/air dampers
Instrument panel speedometer, rev-counter on panel complete with warning lights
Fuel tank capacity 16.5 litres (3.6 gal)
Frame tubular cradle
Fuel consumption 5L per 100 km (57 mpg Imp/ 47 mpg US) CUNA Norms
Speed over 185 km/h (116 m.p.h.)
Dry weight 180 kg (396 lb) approx.
