Engine 90° V-Twin, four-stroke
Displacement 1,064 cc
Maximum power 54 kW at 6,400 rpm
Maximum torque 94 Nm at 5,000 rpm
Exhaust system Steel, twin header pipes connected to twin steel mufflers; three-way catalyzer with Lambda sensor (Euro 3)
Gearbox 5 speed, constant mesh gears with built-in cush drive
Final drive Shaft drive, ratio 8/33 = 1:4.125
Front suspension Marzocchi hydraulic telescopic fork, 45 mm diameter, adjustable separately
Rear suspension Swing arm with 2 hydraulic shock absorbers, preload adjustable
Front brake Dual Brembo Serie Oro stainless steel 320 mm floating discs, 4 piston calipers
Rear brake Single Brembo stainless steel 282 mm floating disc, 2 piston caliper
Tyres 110/90 VB 18" (front) - 150/70 VB 17" (rear)
Length 2,380 mm
Width 815 mm
Height 1,150 mm
Dry weight 251 kg
Fuel tank capacity 19 litres (reserve 4 litres)
Colour range Bordeaux/Black
Source: John Sample Group
